Ultra-Pure Water Solutions for Industrial & Commercial Applications

Maximize Cooling Efficiency • Prevent Corrosion & Scaling • Extend Equipment Life

At SWAS Consultants, we design, supply, and maintain advanced De-Mineralization Plants (DM Plants) engineered to deliver high-purity water for a wide range of industrial and commercial processes. Our DM systems efficiently remove dissolved salts, minerals, and other ionic impurities using ion-exchange technology, ensuring consistent water quality that meets your process requirements.

What is a De-Mineralization Plant?

A De-Mineralization Plant (also known as a Deionization Plant) uses cation and anion exchange resins to remove dissolved ions from raw water. The result is highly purified water with low conductivity and total dissolved solids (TDS), suitable for applications where even minor contaminants can affect performance.

swasconsultans
de mineralization 01 2
star 1
de mineralization 02
de mineralization 03 2
shapeHow It Works

The Dual-Bed Process

SWAS Consultants provides custom-designed DM Plants for high-purity water needs. Ideal for boiler feed, pharma, electronics, and industrial processes.

Cation Exchange Unit

Removes positively charged ions like calcium, magnesium, sodium, and iron by exchanging them with hydrogen (H⁺) ions.

Anion Exchange Unit

Removes negatively charged ions like chloride, sulfate, nitrate, and silica by exchanging them with hydroxide (OH⁻) ions.

Mixed-Bed Units (Optional)

For polishing and achieving ultra-pure water (conductivity < 0.5 µS/cm), often used in laboratory and electronic industries.

System Features – Customized to Fit You

SWAS Consultants provides engineered Demineralization (DM) plants using ion-exchange resins for ultra-pure water in boilers, labs, pharma, and industrial processes.

  • Configurations: Two-bed, mixed-bed, or modular skid systems

  • Capacities: 500 LPH to 100,000+ LPH, scalable on demand

  • Materials: FRP, MSRL, Stainless Steel, suitable for a range of environments

  • Automation: Fully automated regeneration control, conductivity monitoring, PLC/HMI integration

  • Regenerant Dosing: High‑purity HCl / H₂SO₄ (cations), NaOH (anions) with neutralization & safety features

  • High flow-rate designs (customizable from 500 LPH to 100,000+ LPH)

  • Two-bed, mixed-bed, or multiple-stage configurations

  • FRP, MSRL, or SS vessel options

  • Manual, semi-automatic, or fully automatic control panels

  • Regenerant dosing systems with acid/alkali safety features

  • Conductivity & pH monitoring with alarm indicators

  • Compact & skid-mounted systems available

dm_choose_1
dm_choose_2
More about De‑Mineralization Plant Services

Quality Service, Crystal Clear Results

  • Boiler feedwater in power plants and heavy industry

  • High-purity water for pharma, laboratories, electronics, and semiconductor sectors

  • Ultraclean water for food, beverage, and cosmetic manufacturing

  • Technical applications—battery filling, turbine washing, instrument cooling

  • Consistent ultra-pure water (< 15 μS/cm or better) for sensitive processes

  • Reduced fouling, scaling, and corrosion inside downstream systems

  • Long resin lifespan—even with variable feedwater conditions

  • Lower regeneration costs and minimized chemical wastage

  • Compact designs with fast, cost-effective serviceability

  • Tailored designs, optimized through feed water and usage analysis

  • Turnkey solutions: supply, install, automate & commission

  • Technical expertise: resin cleaning, regenerant selection, system tuning

  • Eco‑conscious operations, including spent regenerant neutralization

  • Lifetime support: AMC packages, spare parts, and water quality monitoring

  • Consistent high-purity water output

  • Reduced scaling and corrosion in equipment

  • Custom-designed systems for your feedwater & flow rate

  • Energy-efficient and low regeneration cost

  • Long resin life and easy maintenance

  • Full technical support and AMC options
